This rugged, tan Hensoldt Spotter 60 20-60x72 spotting scope presents a bright, high-contrast image at all magnification levels in a compact design for smaller carrying profile and for concealed observations.
Featuring a Mil-dot reticle in the first focal plane, the Hensoldt Spotter 60 allows reticle-based ranging from all magnification levels. The Mil-dot reticle has red illumination from a single 3V CR2032 battery cell; this illumination will automatically shut off after 3 hours to save battery power. This reticle will also pulse after illumination turn-on to alert the user that battery power is getting low.
The Hensoldt Spotter 60 boasts 85% light transmission, and has a variety of optional accessories including rail segments, laser protection filters, and tripods. The device is environmentally tested to the MIL-STD-810G specification.
Hensoldt Reticle Information
Reticle Measuring System: milradian
Dist. Between Reticle Dots: 10 cm. @ 100 m.
Dist. Between Centering Lines: 1 m. @ 100 m.
Reticle Focal Plane: 1st - magnifying
Illuminated Reticle: yes, red w/auto brightness
Battery Type: 3V CR 2032
Auto Reticle Shutoff: yes, 3 hours
Specification :
Spotting Scope Series Hensoldt Spotter
Warranty 10 years
Variable magnification Yes
Minimal magnification. 20x
Maximum magnification. 60x
Diopter range -2 / +3 Dpt
Lens diameter. 72mm
Min. exit pupil. 1.2mm
Max. exit pupil. 3.6mm
Min. field of view... 19m/1000m
Max. field of view... 49m/1000m
Minimal field of view (deg.) 1.08
Maximal field of view (deg.) 2.8
Min. eye relief. 20mm
Max. eye relief. 20.5mm
Close focus. 0m
Twilight Factor -
Light transmission 85%
Reticle position 1. focal plane - FFP
Reticle illumination Yes
Illumination color -
Daytime-usable illumination Yes
Auto Turn-Off -
Length. 350mm
Width. 90mm
Height. 165mm
Weight. 1770g
Material No
Color Black
Working temperature range -2 / +3 Dpt
Filled with Nitrogen
Focusing system Central
Lens coating Fully Multicoated
Objective diameter 72 mm
Eyepiece diameter -
Eyepiece angle 0°
Objective tread Yes
Body type Fixed
Waterproof Yes
Fogproof Yes
Tripod adaptable Yes
Photo adapter Yes
